Page number 10
Part names and functions 2 Deck 3 Mixer 2 Deck B 1 Browser A 3 Mixer 1 Browser 2 Deck 3 Mixer 6 c k l d 21 2 d c i j 6 9ab 7 8 5 me m n n o 9ab 7 8 5 q p 4 3h g 2 Deck f 4 3 h g 3 Mixer f 2 Deck The screen above shows an example of 2-deck layout. The contents displayed on the screen differ according to the VIRTUAL DJ LE settings. ! The deck layout can be switched by clicking the [ ] button on the computer’s screen. 1 Browser 1 Rotary selector ! Turn: The cursor moves in section A of the above diagram. ! [ SHIFT ] + turn: The cursor moves in section B of the above diagram. ! [ SHIFT ] + press: Folders in section B of the above diagram open and close. * If a panel other than the [ BROWSE ] panel is displayed, turn the rotary selector to display the [ BROWSE ] panel. 2 LOAD button Loads the track selected with the cursor in each of the decks. 10 En
Page number 11
English 2 Deck 3 f button Use this to play/pause tracks. 4 CUE button ! Press: Sets a cue point or moves the cue point. ! [ SHIFT ] + press: The playing position moves to the beginning of the track. 5 SYNC (MASTER) button ! Press: Synchronizes to the master deck’s tempo. ! [ SHIFT ] + press: Sets the master deck for synchronization. 6 TEMPO slider Adjusts the playing speed. 7 CTRL A button ! Press: Turns key control on and off. ! [ SHIFT ] + press: Turns key control, the filter and effects 1 to 3 all off at once. 8 CTRL B button ! Press: Turns the filter on and off. ! [ SHIFT ] + press: Turns key control, the filter and effects 1 to 3 all off at once. 9 FX1 button ! Press: Turns effect 1 on and off. ! [ SHIFT ] + press: Switches the effect types of FX1. a FX2 button ! Press: Turns effect 2 on and off. ! [ SHIFT ] + press: Switches the effect types of FX2. b FX3 button ! Press: Turns effect 3 on and off. ! [ SHIFT ] + press: Switches the effect types of FX3. c AUTO LOOP (MOVE GRID) control ! Turn: Changes the loop length for playback. ! Press: Turns loop playback on and off. ! [ SHIFT ] + turn: Moves the beat grid position. * This function can be used when you upgrade to VIRTUALDJ PRO FULL . ! [ SHIFT ] + press: Sets the manual loop’s in and out points. Turns manual loop playback on and off. d DECK button Switches the deck to be operated. e SHIFT button When another button is pressed while pressing the [ SHIFT ] button, a different function is called out. f SAMPLER button ! Press: Turns the sampler mode on and off. g HOT CUE (DELETE)/SAMPLER button ! Press: When the sampler mode is off, sets or calls out the hot cue point. When the sampler mode is on, plays/stops playback of the sam- ple sound. ! [ SHIFT ] + press: When the sampler mode is off, cancels the hot cue set at the button that is pressed. When the sampler mode is on, if a sample sound is playing, play- back returns to the beginning of the sample sound and continues from there. h Jog dial 0 When the JOG FX mode is off — Scratch When turned while touching a metallic part of the top of the jog dial, the sound is played according to the direction and speed at which the jog dial is turned. — Pitch bend The playing speed can be adjusted by turning the outer part of the jog dial during playback. — Manual search When the jog dial is spun while pressing [ SHIFT ] button dur- ing playback, the track is fast-forwarded/fast-reversed. 0 When the JOG FX mode is on — JOG FX control Effect parameters can be adjusted by turning the jog dial. 3 Mixer i MIC VOL control Adjusts the audio level input to the [ MIC ] terminal. j MASTER VOL control Adjusts the sound level output from the master. ! The adjustment made here does not affect the [ MASTER ] control on the computer’s screen. k HEADPHONES MIX control Adjusts the balance of the monitor volume between the sound of the deck whose [ ] button is pressed and the master sound. ! The sampler sound is output regardless of the position of the [ HEADPHONES MIX ] control. l HEADPHONES VOL control Adjusts the audio level output from the [ PHONES ] terminal. ! The adjustment made here does not affect the [ VOL ] control (headphones volume control) on the computer’s screen. ! The sound of the microphone connected to the [ MIC ] jack is not output from the headphones. m EQ (HI, MID, LOW) controls These adjust the sound quality input to the various decks. [ HI ] (treble range), [ MID ] (middle range), [ LOW ] (low range) n CUE (Headphones cue button) Use this to monitor the sound of the respective decks over the headphones. o Channel Level Indicator Indicates the level of the sound before it passes through the channel faders of the respective decks. p Channel fader Adjusts the sound level output from the various decks. q Crossfader Switches the sound of the decks assigned to the left and right sides of the crossfader for output. En 11
